Pearl Inverter

The Haier HSU-12HFP/WUSDC 1 Ton Inverter AC offers efficient heating and cooling with 13,000 BTU cooling and 13,500 BTU heating capacity. Its DC inverter technology optimizes energy use, reducing electricity costs while ensuring consistent comfort. With 700 m³/h air circulation, quiet operation, and auto-swing louvers, it delivers rapid and even temperature control. Wi-Fi connectivity, self-cleaning, and anti-corrosion materials enhance convenience and durability. Backed by a 10-year compressor warranty, it’s a reliable choice for year-round climate control.

Performance Specifications

Capacity wise:
1-Ton

Category wise:
DC Inverter

Color:
Golden

Cooling Capacity BTU:
13000

Running Current Cooling (A):
1.6 ~ 6.5

Power input Cooling (KW):
0.37 ~ 1.36

Heating Capacity BTU:
13500

Running Current Heating (A):
2.3 ~ 6.0

Power Input Heating (KW):
0.41 ~ 1.35

Other Parameters

Input Power Supply (Ph, VAC, Hz):
1PH,220V ̴, 50Hz

Air Flow Volume (m3/h):
700

Refrigerant Type:
R-32

Refrigerant Amount (G):
750

Indoor & Outdoor Parameters

Indoor Net Dimension (L*W*H) mm³:
850*210*295

Indoor Packing Net Dimension (L*W*H) mm³):
952*389*283

Indoor Net Weight (kg):
11.5

Indoor Gross Weight (kg):
14.1

Outdoor Net Dimension (L*W*H) mm³:
700*245*535

Outdoor Packing Net Dimension (L*W*H) mm³:
845*320*593

Outdoor Net Weight (kg):
26

Outdoor Gross Weight (kg):
29

Features

Cooling:
Yes

Heating:
Yes

Dry:
Yes

Vertical Flapper Auto Swing:
Yes

Horizontal Louvers Auto Swing:
Yes

WiFi:
Yes

Self-Clean:
Yes

Anti-Corrosion:
Yes

Turbo Function:
Yes

UPS Enable:
Yes

Accessories

Installation Kit (Liquid side) Material*Length*Dia*Thickness (mm):
Copper * 2920*6*0.65 (6mm)

Installation Kit (Gas side) Material*Length*Dia*Thickness (mm):
Copper * 2920*9*0.65 (9mm)

Power Cable (Core*mm²):
3*1.5

Communication Cable b/w Indoor & Outdoor (Core*mm²):
4*1.5

Warranty

Compressor: 10 Years

PCB Kit: 4 Years

Parts: 1 Year
